💧 Flow smart, heat fast — the switch your water heater deserves!
The DIGITEN FS-C02 is a compact, brass water flow switch designed for precise activation of water heaters and related systems. Operating across 0-220V AC/DC with a flow detection range of 1-50L/min, it ensures energy-efficient heating by triggering circuits only when water flows. Its robust, waterproof design meets RoHS standards and supports compliance with regulations like California's Title 24, making it an essential upgrade for modern, eco-conscious homes and professional setups.
| ASIN | B07G77169W |
| Actuator Type | Plunger |
| Best Sellers Rank | #602,480 in Tools & Home Improvement ( See Top 100 in Tools & Home Improvement ) #1,551 in Water Heater Replacement Parts |
| Brand Name | DIGITEN |
| Circuit Type | 1-way |
| Connectivity Protocol | X-10 |
| Connector Type | Male Thread |
| Contact Material | Brass |
| Contact Type | Normally Open |
| Control Method | Touch |
| Current Rating | 2 Amps |
| Customer Reviews | 3.7 3.7 out of 5 stars (55) |
| International Protection Rating | IP54 |
| Item Dimensions | 2.36 x 1.18 x 1.1 inches |
| Item Weight | 0.01 Ounces |
| Manufacturer | Ditigen |
| Material Type | Brass |
| Model | FS-C02 |
| Mounting Type | Threaded Mount |
| Number of Items | 1 |
| Number of Positions | 2 |
| Operating Voltage | 220 Volts |
| Operation Mode | automatic |
| Specification Met | RoHS |
| Switch Type | ['Flow Switch'] |
| Terminal | Screw |
| Unit Count | 1.0 Count |
| Upper Temperature Rating | 80 Degrees Celsius |
| Wattage | 50 watts |
C**D
Flow Switch for Tankless water heater for CA title 24 compliance.
This product is used on my tank-less water heater to activate the re-circulation pump. I just momentary turn on than off any faucet in my house for a second and the flow switch activates the re-circulation pump. This is needed to be in compliance with title 24 of CA code. A re-circulation pump is not allowed to be on a timer or on full time. Instead the code requires an activation button located near each faucets. This works better as you don't needed multiple buttons! There is a plastic flow switch but its max flow rate is below the 11gpm of my tank-less. This has a higher flow rate. Note: This flow switch has BSP threads you will need to use BSP to NPT adapters.
L**S
Installed with some effort
I installed this on the cold water supply of my hot water heater to activate my hot water circulation pump. This reduces the amount of water I waste getting hot water to the other side of the house. I am using a RaspPI to activate a solid-state relay for a fixed amount of time once flow is detected. Pros: This is a solid brass construction and there is no barrier penetration between the water and the switch. There is a magnet inside the fitting to detect flow and the magnetic sensor does not have direct contact with water. It requires a flow of about ~1GPM to activate. Cons: The thread IS NOT 3/4" NPT-Male. It is a Metric BSPT 3/4" Male thread. It is straight mechanical thus requiring a hose washer. I had to purchase a brass adapter to convert from BSPT to NPT and that fitting cost as much as this sensor. This manufacturer should offer this product threaded in both NPT and BSPT.
B**.
Getting bad after 10 days
It’s working good for to weeks only and got bad Not recommended
K**D
working great.
working great, it turns on the relay that powers my hot water on demand 220 volt water heater unit.
V**5
Not reliable
My flow switch stays made under normal water pressure, even if there is no flow. No water pressure and no water movement, then it might revert back to an open state but a lot of times not.
K**.
Works perfectly!
Very low flow restriction with this switch! Mounted horizontally with no issues. Switch closes when water is flowing and opens when the flow stops. As advertised, it uses G3/4" connections which are not tapered, so it requires a vinyl washer (same size as a garden hose) on each female connection to make a seal. I used G3/4" - 3/4" NPT adapters (available elsewhere on Amazon) and several garden hose washers and the setup is leak free.
P**T
Nice item
Quality item at a nice price point. Time will tell how it holds up, but for now it was a good purchase
A**R
OK but repeatability is suspect
Used for control of water pump through a relay to carry the starting amps. It doesnt sense the water flow perfectly every time . Somtimes there is a slight lag. However there are many other unknown factors in this type of water pressure booster system which may be the cause. Pity it couldnt handle 4 or 5 amps directly>
