High Input Impedance:DC 20 KΩ/V. AC 9 KΩ/V .Strong Magnet Pivot_Jwell Movement built-in .Compact soft Protective Holster alongside .Perfect Overland Protection incl. Two fast-acting Fuses 0.5A & 10A (Just one Fuse 0.5A for HD-390B) .Adjustable Real tilt stand device with Hook-up place .AC Voltage Range (±4.0% F.S.) 10/50/250/1000V .DC Voltage Range(±3.0% F.S.) 0.1/2.5/10/50/250/1000V .DC Current Range (±3.0% F.S.) 0.1/0.5/2.5/25/250mA, 10A(Just for HD-390A) .Resistance Ranges (±4.0% of Arc.) X1. X10. X100. X1K(C1). X10K(0.2~20 MΩ) .Capacitance Test With Additional Tool Kit(CT-1) C1: 100pF~0.025uF/2.5uF/25uF(±3.0% F.S.) C2:Big capacitor upto 2000uF directity via jacks of tester .Decibels Test:-20~ +62dB with an external Polyester capacitor 0.047uF/400V .Continuity Test With Buzzer(Just for HD-390A) .Battery Test:1.5V. 9V .Leakage Current & Diode Test .Transistor & LED Test via special Hfe socket .Dimensions & Weight:160*105*40mm & 340g approx.. .Power Supply:6F22 9V 1pc. AA size 1.5V 2pcs .Over voltage Category CAT ||| 500V, CAT || 1000V
